Features

Rated Load

Kg

32000

Load Center

mm

1220

Wheelbase

mm

4800

Weight

Weight

kg

38000

Chassis

Tire Specs:Front

16.00-25

Tire Specs:Rear

14.00-24

Tires Qty,front/rear(X-dreve wheels)

4/2

Wheel tread:Front

mm

2270

Wheel tread:Rear

mm

2300

Dimensions

Mast/carriage tilt angle(front/rear)

Degree(°)

6/12

Mast height(fork lowering)

mm

4060

Mast lifting height

mm

4000

Max.height

mm

6030

height to head guard(height to cab)

mm

3560

Overall height（with forks)

mm

9460

Fork front verticaal sueface to the rear end of the vehicle

mm

7260

Overall width

mm

3360

Fork dimension

mm

2400*320*110

Fork carriage width

mm

3130

Mast min ground(with load)

mm

350

Wheelbase center min ground(with load)

mm

450

Min.turning Radius

mm

6800

Travel speed(with load/without load)

km/h

24/28

Front overhang

mm

1080

Rear overhang

mm

1220

Performance

Max.lifting speed(with load/without load)

mm/s

260/280

Traction

KN

190

Gradeability(with load/without load)

%

20/22

Engine

Manufacture

WeiChai Engine

Model

WD10G240E21

Rated Output

(Kw)

175

Optional

cummins

6CTA8.3-C260-II

Rated Output

(Kw)

194

Cylinder No

6

Others

Transmission gears(Front/rear)

2/1
